MSI PRO B760M-A WIFI DDR5 12TH/13TH GEN MOTHERBOARD
Specification
| Basic Information | ||
| Supported CPU | Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
|
| Chipset | INTEL B760 | |
| Form Factor | mATX 243.84mmx243.84mm |
|
| Audio | Realtek ALC897 Codec 7.1-Channel High-Definition Audio |
|
| Expansion Slots | ||
| PCI | 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4 | |
| Supported Memory | Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6800+ MHz • 1DPC 2R Max speed up to 6400+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5600+ MHzSupports Intel XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
|
| Maximum Memory | 192GB | |
| Graphics | ||
| Graphics | 2x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 2x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| HDMI | 2x HDMI | |
| Display Port (s) | 2x DisplayPort | |
| USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 4x USB 3.2 Gen1 Type A (Front) 1x USB 3.2 Gen1 Type C (Front) 2x USB 3.2 Gen2 Type A (Rear) |
|
| LAN Port (s) | Realtek RTL8125BG 2.5G LAN | |
| Wireless Communication module | Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth® 5.3, FIPS, FISMA |
|
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
|
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | |
| Audio | 3x Audio Connectors | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen1 Type C ports |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Others | ||
| Special Features | 4x EZ Debug LED | |
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
Description
MSI PRO B760M-A WIFI DDR5 12TH/13TH GEN MOTHERBOARD
The MSI PRO B760M-A WIFI DDR5 motherboard is a high-performance micro-ATX board crafted for users seeking reliability, cutting-edge speed, and future-ready compatibility. Supporting Intel’s 12th, 13th, and 14th Gen Core processors on the LGA 1700 socket, it harnesses the power of the B760 chipset to deliver exceptional multitasking and responsiveness. This board stands out with its support for DDR5 memory, enabling ultra-fast data transfer speeds up to 6800+ MHz across four DIMM slots, offering seamless performance for demanding applications and next-gen gaming. Built with professionals and enthusiasts in mind, the motherboard offers comprehensive display output options including dual HDMI 2.1 and DisplayPort 1.4, capable of pushing crisp 4K visuals—ideal for creative tasks, content consumption, and multi-monitor setups. Expansion is made effortless with its PCIe 4.0 slot that unlocks full GPU potential, along with additional PCIe and M.2 slots for added versatility. Two M.2 slots provide blazing-fast NVMe SSD support, one directly linked to the CPU for reduced latency and faster boot times. Connectivity is a strong point with integrated Intel Wi-Fi 6E, delivering ultra-low latency wireless speeds on the 6GHz band, and Realtek 2.5G LAN ensuring stable, high-speed wired networking. Enhanced with Bluetooth 5.3, the board supports modern peripherals with improved range and efficiency. MSI’s robust build quality includes extended heatsinks, reinforced power delivery, and premium-grade components to ensure sustained thermal performance and system longevity.
MSI PRO B760M-A WIFI DDR5 12TH/13TH GEN MOTHERBOARD Price in BD
The Best price of a MSI PRO B760M-A WIFI DDR5 12TH/13TH GEN MOTHERBOARD is 19,200 TK. you can visit Our showroom( Suvastu Arcade ICT Bhaban, Shop: 04,05( Ground Floor), 46-48 New Elephant Road, Dhaka-1205 ) and Join Our Facebook Page.
